Silver Wire Mesh

HOME > Brass Mesh & Special Material > Silver Wire Mesh >

Silver Wire Mesh Quick Details:

  • Usage: Electronic Industry, Power Industry,
  • Material: Silver
  • Wire Diameter: 0.05 mm-0.35 mm
  • Technology: Woven
  • Mesh Size: 20-60
  • Woven Type: Plain Woven
  • Width: 0.3 m-2 m
  • Transport Package: According to Order
Properties Detail

Silver Wire MeshSilver Wire MeshSilver Wire Mesh

Silver mesh features is Superior heat resistance. High temperature and corrosion resistance. Strong conductivity of electricity.Attractive outlook and advantage is With favorable conductibility, chemical stability, thermal conduction and extensibility. Low resistively, Highly conductive capacity.Silver mesh is widely used in electronic industry, power industry, aerospace and other industries.

Silver Wire Mesh Specifications:

Mesh Wire Diameter Opening Opening
inch mm inch mm Area %
20mesh 0.014 0.35 0.036 0.91 51.8
20mesh 0.009 0.23 0.041 1.04 67.2
24mesh 0.014 0.35 0.028 0.71 44.2
28mesh 0.01 0.25 0.026 0.66 51.8
30mesh 0.011 0.28 0.022 0.55 44.8
30mesh 0.0065 0.16 0.027 0.68 64.8
35mesh 0.012 0.3 0.017' 0.43 33.8
35mesh 0.01 0.25 0.019 0.48 42.4
40mesh 0.01 0.25 0.015 0.38 36
40mesh 0.0095 0.24 0.016 0.4 38.4
50mesh 0.009 0.23 0.011 0.28 30.3
50mesh 0.008 0.20 0.012 0.3 36
60mesh 0.0075 0.19 0.009 0.22 30.5
60mesh 0.0059 0.15 0.011 0.28 40.2
