Duplex Stainless Steel Wire Mesh

Galvanized Wire Mesh Quick Details:

Usage:Printing,filter,space flight,oil,chemical industry
Material:super duplex stainless steel wire mesh
Weave Style:Plain Weave
Color:Silver
Type:Weave Wire Mesh
Wire Diameter: 0.018 mm-2.5 mm
Length: 30 m per roll or as required
Roll size: 1mx30m, 1.22mx30m, 1.5mx30m
Delivery Time: 10 days

Properties Detail

Super Duplex stainless like Duplex, is a mixed microstructure of austenite and ferrite (50/50) which has improved strength over ferritic and austenitic steel grades. The main difference is that Super duplex has a higher Molybdenum and Chromium content which gives the material greater corrosion resistance.

Super Duplex has the same benefits as its counterpart - it has lower production costs when compared with similar ferritic and austenitic grades and due to the materials increased tensile and yield strength, in many cases this gives the purchaser the welcomed option of purchasing smaller thicknesses without the need to compromise on quality and performance.

Duplex Stainless Steel Wire Mesh Specifications:

Mesh Inch	S.W.G	Aperture (mm)	Wire Diameter (mm)	Effective (%)	Weight (Kg/m2)
5mesh	22	4.36	0.711	76	1.3
8mesh	24	2.5	0.559	67	1.5
18mesh	30	1.1	0.315	60	0.85
20mesh	30	0.95	0.315	58	0.95
24mesh	32	0.78	0.274	55	0.85
28mesh	34	0.67	0.234	50	0.75
32mesh	34	0.56	0.234	50	0.84
50mesh	38	0.36	0.152	46	0.58
60mesh	40	0.3	0.122	50	0.45
80mesh	40	0.198	0.12	44	0.58
100mesh	42	0.154	0.1	37	0.5
120mesh	44	0.13	0.081	40	0.39
