Detailed instructions for the installation of the razor wire

Many customers often ask questions, buy your razor wire, is responsible for the installation? Macrokun razor wire supplier tells you that if you order a large quantity, or the road is close, our company has a professional installation team to install for you, but relatively speaking, our past workers car, Malton, eat and drink All of them are expenses. The customers with small purchases or long distances have to install them themselves. In order to facilitate your own installation, our company has compiled a set of detailed steps for installing the barbed wire according to the actual production experience.

According to the installation procedure of the razor wire, the project department divided the workers into column bracket installation, longitudinal hanging wire installation and knife-rolling rolling cage to form three small shifts, which formed the flow operation. Due to the special structure of the razor wire, the construction work was slightly inattentive. It will be injured, and the project department purchased extra thick gloves to prevent workers from being stabbed.

(1) The razor wire of the blade is fixed by a lancet with a razor rope. The adjacent two laps are fixed with a barbed wire every 120 degrees. After opening, a corrugated mesh is formed. After closing, the diameter of the lancet is 50cm. The cross-ring installation pitch is 20cm and the diameter is not less than 45cm.

(2) The razor wire is connected by the stab wire connection buckle and the longitudinal rib fixed on the bracket. The connection between the longitudinal rib and the bracket is tightened and fixed by Φ2.5mm cold drawn galvanized steel wire after 2 turns, the bracket is set. In the column and mid-span position of the 3m protective fence, the span is set in the upper part of the column, and the bracket and the protective fence are connected by the bracket hoop. For the protective fence with the metal mesh installed, the blade barb wire directly adopts Φ2.5mm cold. The galvanized steel wire or the barbed wire connection buckle is fixed on the metal mesh horizontal piece and the wire.

(3) The vertical distance of the lower edge of the razor wire from the upper edge of the reinforced concrete fence is 0.05m.

razor wire
